Dimensions, including the middle and upper rack (length x width x height): 565mm x 308mm x 182mm
Dimensions, only stove (length x width x height): 482mm x 172mm x 87mm
Burner dimensions: 6.8 inches (172 mm diameter)
Horizontal distance from the center of the burner to the electrical switch inlet: 325±2.5mm
Detachable middle and upper rack dimensions: 308 mm diameter, 182 mm height
★Dimension Diagram

Functions:
•Ideal for all kinds of restaurants, which include: Snack bar, sea food and stir-fried restaurants.
•Suitable for cooking soup or brewing broth.
•Suitable use for bottled gas cylinder(includes natural gas).
【Uses the bottled gas cylinder. Please use the 280~500 mmH2O low-pressure regulator. Do not use regulators over 500 mmH2O】

Features:
•High-precision rack design allows the flame to envelop the pot and maximizes the heat energy.
•Medium heat; medium heat is slightly brighter and produces a lot of heat, generally used for braising and boiling.
•Copper burner reduces the likelihood of corrosion, durable, medium heat.
•Equipped with electrical ignition system.

12-core Low Pressure Electrical Spray Stove (Copper material) heat and volume test:
▲Tested with 2000 mL lukewarm water on high heat
    Tested with 500mmH2O standard gas pressure value
•Heat performance: water boils in 6 minutes and 14 seconds
•Volume performance: 69.2db-70.7db
