Dimensions, only stove and bottom rack (length x width x height): 680mm x 345mm x 139mm
Dimensions, only stove (length x width x height): 665mm x 310mm x 115mm
Burner dimensions: 12 inches (309 mm diameter)
Horizontal distance from the center of the burner to the tube inlet: 495±2.5mm
Bottom rack dimensions: 345 mm diameter, 24 mm height
Gas connector hose:
For bottled gas cylinder: 9.5±0.5mm inside diameter rubber hose
For natural gas: 12.7±0.6mm inside diameter rubber hose, 15.9±0.9mm inside diameter rubber hose
Inlet: on the left of the standard product (can be customized to the right)
★Dimension Diagram

Functions:
•Ideal for all kinds of restaurants, which include: Snack bar, sea food and stir-fried restaurants.
•Suitable for cooking soup or brewing broth.
•Suitable use for bottled gas cylinder(includes natural gas).
【Uses the bottled gas cylinder. Please use the 280~500 mmH2O low-pressure regulator. Do not use regulators over 500 mmH2O】

Features:
•High-precision rack design allows the flame to envelop the pot and maximizes the heat energy.
•Medium heat; medium heat is slightly brighter and produces a lot of heat, generally used for braising and boiling.
•Enlarged tip on each branch results in moderate cooking power.
•Manual ignition switch, requires external source of ignition.
•Left knob of the manual ignition switch is the outer ring main burner, right knob is the inner ring main burner, middle knob is the pilot light; turn clockwise to turn off, counterclockwise to turn on.
•Does not contain upper rack and bowl.
